Australian and New Zealand standard Parallel Flange Channels

 Parallel Flange Channels, PFC steel section

Australian and New Zealand Standard Parallel Flange Channels


Steel parallel flange channels (steel PFC) is one of Australian and New Zealand standard structural steel channel section which with parallel flange, parallel flange channels was known as mild steel parallel flange channels and U channel which was manufactured by Australian and New Zealand quality standard AS/NZS 3679.1 to finish, which is often used to be made of structural steel, We offer hot rolled parallel flange channels size range from 75PFC5.92 to 200PFC22.9, the available steel grade:,Q235B,Q345, grade 300 plus, the available length: 6 meters-12 meters or we can cut size to meet your project, we can also galvanized parallel flange channels if you need.

Australian Parallel Flange Channels

Size

Kg/m

D

B

T

t

mm

mm

mm

mm

75PFC5.92

5.92

75

40

6.1

3.8

100PFC8.33

8.33

100

50

6.7

4.2

125PFC11.9

11.9

125

65

7.5

4.7

150PFC17.7

17.7

150

75

9.5

6

200PFC22.9

22.9

200

75

12

6
